20x Zoom USB SDI Webcam Suited Rau Video Conference System
20 x zoom
F{0}}7-94.0 mm
USB, SDI, HDMI, RJ45, Mic hauv cov zis video
Yias: {{0}} degree Tilt: 0 degree ~ 120 degree
Ze-End 55.5 degree - Far-End 3.0 degree
1/3 "HD Xim CMOS 2.38 mega pixel
RS-232, RS-485, IR chaw taws teeb tswj
- Ceev ceev
- Kev Muaj Peev Xwm Zoo
- 24/7 Cov Neeg Siv Khoom
Khoom Taw qhia
Tenveo USB, SDI, HDMI, RJ45, Mic hauv Video Conference Lub Koob Yees Duab 20x Optical Zoom
Lub teeb siab:
Pom hauv 1080p, 2.38 Mega Pixel.
Crystal clear High Definition 1080p video nrog kev poob qis, cia koj sawv ze rau pom thiab cuam tshuam nrog koj pab neeg. Distortion dawb ntawm video zoo.
Yooj yim txuas koj lub koob yees duab rau PC, Mac lossis ChromeBox yam tsis tas yuav muaj software ntxiv.
Siv koj cov software nyiam.
Ua haujlwm nrog txhua qhov kev sib tham video hauv online uas tsis tas yuav muaj cov tsav tsheb ntxiv lossis kev sib txuas ua ke.
1.Peb muaj cov qauv hauv Tshuag, tib hnub shipping. Rau kev txiav txim loj peb xa tuaj tsis pub dhau 3-7 hnub ua haujlwm.
2.Peb tuaj yeem xa tuaj rau koj los ntawm DHL / FEDEX / UPS / TNT / EMS lossis lwm txoj kev xa khoom raws li koj cov lus qhia nrog tus me nyuam ceev tshaj plaws, tus nqi pheej yig tshaj hauv txoj kev nyab xeeb.
Application Scenario:
Product Overview:
20x optical zoom
USB/SDI/HDMI Video tso zis
Sleek thiab ntse tsim
Plug & Ua Si USB Connectivity
Crystal ntshiab HD 1080P duab zoo
Preset: 9 ntawm IR chaw taws teeb chaw taws teeb (256 ntawm RS232)
Kev pom dav dav uas tsis muaj kev cuam tshuam video
1/3 nti zoo, 2.38MP (16:9) CMOS sensor
Superior zoo nrog tag nrho iav Lens Khoom
Txhawb nqa qab nthab, phab ntsa mount thiab tripod mount (Rov qab mountable)
2D thiab 3D NR rau cov yeeb yaj kiab zoo tshaj plaws hauv cov teeb pom kev sib txawv
Txhawb Visca, Pelco-P, thiab Pelco-D raws tu qauv, RS232 / RS485 Lub Koob Yees Duab Tswj
Tau tshaj nrog feem ntau ua video conferencing software thiab platform
Siv txoj siv sia siv thev naus laus zis the PTZ yog ultra-ntev thiab nrawm, thaum ua tau zoo heev
Khoom Parameter:
Khoom No. | TEVO-UHD 20 N |
Duab Sensor | 1/3 nti HD CMOS |
Muaj txiaj ntsig pixel | 2.38 mega pixel (16:9) daws teeb meem |
Kab rov tav daws teeb meem | 1080P30/25, 1080I60/50/30/25, 720P60/50 |
Teeb liab txheem | NTSC/PAL |
Zoom | 20x optical zoom |
Focal ntev | F{{0}}.7mm(dav)-94.0(tele) |
Kab rov tav | Ze-kawg 55.5 degree -Far-end 3.0 degree |
Tau txais kev tswj hwm | Auto/manual |
Ua kom pom tseeb | Auto/manual |
SNR ratio | Ntau dua lossis sib npaug li 50dB |
Shutter ceev | 1/1 sec rau 1/10000s (22 kauj ruam) |
Preset txoj hauj lwm | IR chaw taws teeb tswj txhawb 9 presets PELCO raws tu qauv txhawb 256 presets |
Pan / Tilt txav ntau | Yias: 340 degree (max ceev 80 degree / S), qaij: 120 degree (max ceev 60 degree / S) |
Tswj lub davhlau ya nyob twg | RS -232, RS485 |
Tswj raws tu qauv | VISCA, PELCO-D, PELCO-P(RS-232, RS485) |
Video tso zis | USB, SDI, HDMI, RJ45, Mic hauv |
Txo suab nrov | 2D/3D |
Ua haujlwm kub | -10 degree -~50 degree |
Cia kub | -20 degree ~ 60 degree |
Baud tus nqi | 2400/4800/9600/19200bps |
Decoder | Ua-hauv |
Chaw nyob teeb | 1~256 |
Kev teeb tsa | Txhawb desktop, Tripod, Phab ntsa mount thiab Qab nthab mount |
Fais fab mov | DC12V / 2A |
Kev siv fais fab | 12 W |
Net nyhav / tag nrho qhov hnyav | 1.7kg / 3.5kg |
Dimension (LXWXH) | 260 * 175 * 180 hli / 296 * 255 * 218mm (ua ntej / tom qab ntim) |
Khoom siv | DC 12V fais fab adaptor, IR chaw taws teeb tswj, phau ntawv qhia, USB cable 3 meters, phab ntsa brackets & screws. |
