30X HDMI Chaw Haujlwm Lub Rooj Sib Tham Lub Koob Yees Duab
2.38 mega pixel (16:9) daws teeb meem
USB, SDI, HDMI, RJ45, Mic hauv cov zis
30x optical zoom
Preset: 9 ntawm IR chaw taws teeb chaw (256 ntawm RS232)
VISCA, PELCO-D, PELCO-P (RS-232, RS485)
Txhawb desktop, Tripod, Phab ntsa mount thiab Qab nthab mount
- Ceev ceev
- Kev Muaj Peev Xwm Zoo
- 24/7 Cov Neeg Siv Khoom
Khoom Taw qhia
Lub koob yees duab sablaj rau kev pabcuam hauv pawg ntseeg
Product Overview:
30x optical zoom
Sleek thiab ntse tsim
Crystal ntshiab HD 1080P duab zoo
Muaj tseeb, du thiab ntsiag to PTZ Movement
Preset: 9 ntawm IR chaw taws teeb chaw (256 ntawm RS232)
Kev pom dav dav uas tsis muaj kev cuam tshuam video
1/3 nti zoo, 3.28MP (16:9) CMOS sensor
Superior zoo nrog tag nrho iav Lens Khoom
USB, SDI, HDMI Video Output.
Txhawb nqa qab nthab, phab ntsa mount thiab tripod mount (Rov qab mountable)
2D thiab 3D NR rau cov yeeb yaj kiab zoo tshaj plaws hauv cov teeb pom kev sib txawv
Txhawb Visca, Pelco-P, thiab Pelco-D raws tu qauv, RS232 / RS485 Lub Koob Yees Duab Tswj
Tau tshaj nrog feem ntau ua video conferencing software thiab platform
TEVO-UHD30N 2.38MP 30x optical Zoom PTZ Sab Hauv Tsev Lub Koob Yees Duab HD1080P 3G-SDI HDMI Lub Rooj Sib Tham Lub Koob Yees Duab Rau Live Streaming Lub Koom Txoos Kev Pabcuam
HD 1080P 1920 * 1080
1/3" HD CMOS 30x Optical Zoom
3G-SDI thiab HDMI Video tso zis
Lub kaum sab xis: 340 degree qaij: 120 degree
Tau tshaj software Lub Rooj Sib Tham Lub Koob Yees Duab Rau Live Streaming Lub Koom Txoos Kev Pabcuam:
Khoom Parameter:
Qauv No. | TEVO-UHD 30 N |
Duab Sensor | 1/3 nti HD CMOS |
Muaj txiaj ntsig pixel | 3.28 mega pixel (16:9) daws teeb meem |
Kab rov tav daws teeb meem | 1080P 60/50/30/25, 1080I 60/50fps, 720P 60/50 |
Teeb liab txheem | NTSC/PAL |
Zoom | 30x optical zoom |
Focal ntev | F{{0}}.7mm(dav)-140.0(tele) F=1.6mm(dav)- Kaw(tele) |
Kab rov tav saib lub kaum sab xis | Ze-kawg 69.5 degree -Far-kawg 2.7 degree |
Yam tsawg kawg illumination | 0.25Lx(on) |
Video hom ntawv | MJPEG/YUY2/H.264 |
Ua kom pom tseeb | Auto/manual |
SNR ratio | Ntau tshaj lossis sib npaug li 50dB |
Shutter ceev | 1/25 s〜 1/10000s |
Preset txoj hauj lwm | Chaw taws teeb tswj txhawb 9 presets PELCO Control Protocol txhawb 256 presets |
Pan / Tilt txav ntau | Yias: 340 degree (max ceev 80 degree / S), qaij: 120 degree (max ceev 60 degree / S) |
Tswj lub davhlau ya nyob twg | RS -232, RS -485 |
Cim generator | Built-in OSD Menu |
Tswj raws tu qauv | VISCA, PELCO-D, PELCO-P(RS-232, RS485) |
Video tso zis | 3G-SDI, HDMI |
Txo suab nrov | 2D/3D |
Ua haujlwm kub | -10 degree -50 degree |
Ua haujlwm av noo | -20 degree -60 degree |
Baud tus nqi | 38400/9600bps |
Decoder | Ua-hauv |
Chaw nyob Set | 1~256 |
Kev teeb tsa | Txhawb desktop, Tripod, Phab ntsa mount thiab Qab nthab mount |
Fais fab mov | DC 12V / 2A |
Hwj chim | 12W |
Qhov hnyav | 1.25kg / 2.05kg (net / tag nrho qhov hnyav) |
Loj | 212 * 160 * 172mm / 260 * 217 * 197mm (ua ntej / tom qab ntim) |
Khoom siv | DC 12V fais fab adaptor, IR chaw taws teeb tswj, phau ntawv qhia, Qab nthab thiab cov ntsia hlau. |
